Spare Part List

Manual tape dispenser 50 mm 161-21-402

PDF-Download



Spare Part List

56402-001
base plate
56402-002
handle, completely with lever
56402-003
cover plate
56402-004
front contact pressure, completely with arbor and screws
56402-004a
front contact pressure, alone
56402-005
knife pillar completely with screws
56402-006
zigzag knife
56402-007
cover plate for knife
56402-009
swivel frame, completely with contact pressure
56402-010
tripping lever
56402-011
tape threading path-roll, completely with arbor and screws
56402-011a
synthetic bush alone (pair)
56402-012
return stop with spring
56402-013
leadingplate
56402-014
tensionspring only fpr return stop
56402-015
safety catch
56402-016
arbor for safety catch, completely with screws and nut
56402-017
rotary spring for safety catch
56402-018
distance bar with screws
56402-019
tension spring for swivel frame
56402-021
screws with nut for grasp
56402-022
bolt, completely with brake, arbor and screws
56402-022k
recessed-head screw M5x10
